Model / Part #6 1034 0010
Special Order Product · Delivery 1–2 WeeksDelivery is 1–2 weeks once your order is placed. Questions? Call 1-888-598-6657 or contact us.
Stock Item · Ships Within 2–3 Business DaysIn stock at TrueNorth — your order ships within 2–3 business days.
Call for price
Pricing for this size is by request. Click Request pricing and we'll get back to you within 1 business day, or give us a call.
Free shipping on tools over $299.99Under $299.99, shipping is calculated at checkout · Shipping details
Key specifications
- Max. Bolt Size: Up to 2-1/8″ (M 56)
- Tightening Torque: Up to 3240 ft-lbs.
- 1/2″ to 1-1/2″ square drive
- Certain models available for underwater use
Features & applications
- Air impact wrenches for tightening and removing bolts and screws up to 2-1/8″.
- For industrial, mining, assembly and subsea applications.
- ATEX certified for Ex zones (Ex II 2 GcT6).
Specifications
| Order No. | Square Drive | Max. Bolt Size | Tightening Torque (Hard) | Weight | ATEX Class |
|---|---|---|---|---|---|
| 6 1034 0010 | 1/2″ | 3/4″ (M 20) | 450 ft-lbs. | 5.5 lbs. | Ex II 2 GcT6 |
| 6 1316 0050 | 3/4″ | 1-1/8″ (M 30) | 995 ft-lbs. | 12.3 lbs. | Ex II 2 GcT6 |
| 6 1316 0070 | 3/4″ (underwater) | 1-1/8″ (M 30) | 995 ft-lbs. | 12.3 lbs. | - |
| 6 1316 0040 | 1″ | 1-1/8″ (M 30) | 995 ft-lbs. | 12.6 lbs. | Ex II 2 GcT6 |
| 6 1316 0060 | 1″ (underwater) | 1-1/8″ (M 30) | 995 ft-lbs. | 12.6 lbs. | - |
| 6 1410 0010 | 1″ | 1-3/8″ (M 36) | 1620 ft-lbs. | 24.3 lbs. | Ex II 2 GcT6 |
| 6 1417 0040 | 1-1/2″ | 2-1/8″ (M 56) | 3240 ft-lbs. | 26.9 lbs. | Ex II 2 GcT6 |
Pricing: call 1-888-598-6657 or click Request pricing for a quote on any model.
🔧 Manuals & Parts
Parts diagrams and manuals for model 6 1034 0010
Need a replacement part for your CS Unitec? Our parts department can help: call 1-888-598-6657 or 604-873-5394, email sales@wctool.ca, or shop all parts.
