Chicago Pneumatic CP9121BR 5" Angle Grinder 5/8" Spindle โ 6151957221
5"(125 mm) PNEUMATIC ANGLE GRINDER
Designed for general maintenance applications, this angle grinder series offers efficiency with its power of 0.8 hp (600W) and high durability with its helical bevel gear design & aluminum alloy housing. The range consist of 7 models: 2x 4" wheel (3/8"- 24 spindle thread), 2x 4.5" wheel (3/8"- 24 & 5/8"- 11 spindle thread) and 3x 5" wheel (M14 & 3/8"- 24 & 5/8"- 11 spindle thread).
Features
- Helical bevel gear design & aluminum alloy housing for high durability
- Keyless adjustable protective guard for better security
- Ergonomic side handle
Specifications
| Free Speed | 12000 rpm |
| Air consumption at free speed | 21 cfm |
| Guard max rotation | 180 ยฐ |
| Guard positions | 9 |
| Output Spindle Thread | 5/8-11 UNC |
| Wheel/Disc diameter | 5 in / 125 mm |
| Sound Power | 95 dB(A) |
| Sound Pressure | 84 dB(A) |
| Vibration | 28.2 ft/sยฒ |
| Air consumption at load | 27 cfm |
| Air inlet thread size | 1/4 NPT |
| Max dynamic air working pressure | 90 psi |
| Max power | 0.8 hp |
| Length | 9.45 in |
| Weight | 4.63 lb |
| CP part # | 6151957221 |
Chicago Pneumatic tools are ordered in for you and usually ship within 1โ2 weeks. Need a quote on multiple units or help choosing a model? Send us a quote request or call 604-873-5394.
Sold by TrueNorth Industrial Tool Company. Ships from Burnaby, BC.
🔧 Manuals & Parts
Parts diagrams and manuals for model 6151957221
Need a replacement part for your Chicago Pneumatic? Our parts department can help: call 1-888-598-6657 or 604-873-5394, email sales@wctool.ca, or shop all parts.
