Chicago Pneumatic CP8609CQ Pack 36V 2.5AH – 6151571140

Description

1" Battery Torque Wrench Connected Quality dual trigger

The CP8609CQ is a high-precision battery torque wrench offering a range of tightenings from 250 Nm / 185 ft.lb to 900 Nm / 665 ft.lb with a precision of +/- 4%. It features angle tightening, counting sequences, and is customizable through the CPLinQ app for traceability. This kit comes complete with S type reaction bar, batteries, charger, and case, optimized for user-friendly handling and performance.

Features

• CPLinQ app for better control and traceability
• Angle tightening
• Counting sequence to avoid missed tightenings
• Automatic reaction arm release

Specifications

Battery capacity	2.5 Ah
Battery type	Lithium-ion
Battery voltage	36 V
Max Ambient Operating Temperature	140 ºF
Max Recommended Ambient Charging Temperature	113 ºF
Min Ambient Operating Temperature	32 ºF
Min Recommended Ambient Charging Temperature	32 ºF
Sound Power (dba)	<83
Sound Pressure	58 dB(A)
Uncertainty vibration-K	1.8 ft/s²
Vibration (m/s²)	<2.5
Max Ambient Storage Temperature	140 ºF
Min Ambient Storage Temperature	-4 ºF
Battery Weight	1.76 lb
Height (H)	11.22 in
Length (L)	13.43 in
Width (W)	3.03 in
Power weight ratio	180 Nm/kg
Side to Center	1.32 in
Weight	9.26 lb
Free Speed	15 rpm
Max torque in forward	664 ft.lbf
Recommended Torque	531 ft.lbf
Torque Control System	Shut-off-current control
Adjustment	Digital
Handle type	Pistol
Main Material type	Steel
Output drive size (in)	1
Reversible	Yes
Starting system	Double-trigger
CP part #	6151571140

Chicago Pneumatic tools are ordered in for you and usually ship within 1–2 weeks. Need a quote on multiple units or help choosing a model? Send us a quote request or call 604-873-5394.

Sold by TrueNorth Industrial Tool Company. Ships from Burnaby, BC.
